Chazy 4K Family
Chazy 4K Family of five 4K 4:4:4 Dante AV-A & JPEG 2000 Tx and Rx endpoints, including a 2-Gang, Decora Style Wall Plate.
Mineola Family
Mineola Family of three Dante XLR Audio Bridges; 2x2, 4x4, 8x8 all with Primary and Secondary Dante Network ports, and locking etherCON connectors.
Darwin HD family
Darwin HD family of three low cost 4:4:4 H.265 AV over IP distribution system with central control box, designed for sports bars and retail spaces.
Video Wall Family
Video Wall Family of two, a 4x4 and 8x8 which double as a Multiview, and triple as a Matrix.
CHAZY 4K Family
Dante AV-A™
JPEG 2000
2160 60Hz 4:4:4 HDR
HDCP 2.2 compliant
Advanced EDID Management with Scaling
Dante AV-A™ licence included
7.1ch Dolby Atmos Audio
KVM
Video Wall up to 9x9
True Multicast support
Dual network ports
TAA Compliant
Bridging the best of both worlds, Dante AV-A works seamlessly with Dante Controller for full routing ability, whilst JPEG 2000 is a visually lossless, super low latency video codec.
Dante® Audio included.
With the included Dante AV-A licence, the Chazy 4K also includes 2x2 Dante Audio. Extract audio from an HDMI source and send it to external speakers via Dante's 2x2 audio channels, or embed Dante audio streams into the HDMI output.
Dante AV-A™ included.
All Chazy 4K products come with the Dante AV-A licence included so there are no hidden costs and nothing left to do other than plug them in, and open up Dante Controller to start your routing.
CHAZY 4K TX
LOW LATENCY DANTE AV-A™ HDMI ENCODER
CHAZY 4K USB-C TX
LOW LATENCY DANTE AV-A™ HDMI AND USB-C ENCODER
CHAZY 4K RX
LOW LATENCY DANTE AV-A™ HDMI DECODER
CHAZY 4K Wall Plate TX
LOW LATENCY DANTE AV-A™ HDMI AND USB-C ENCODER
CHAZY Control
Advanced Control and Management Box
Dante® Controller in hardware. A world first.
Chazy Control box has taken the amazing Dante Controller a step further by building it into hardware. The benefits of this include:
No need to run any software.
You can now control your entire Dante network from any device with a web browser including iPad, Tablet, Smartphone.
Control from Q-SYS, Crestron, and more using the free API.
Darwin HD family
1080 60Hz in 4:4:4
H.265. Hardware accelerated encoding
PoE
Left & Right analog breakout over Phoenix
Advanced EDID Management with Scaling
One to One. One to Many
Multicast. Unicast
Video Wall up to 9x9
TAA Compliant
The Ultimate HD AV over IP solution.
Meet Darwin HD Family. The Darwin HD Family is designed for distributing 1080p 60Hz resolution in 4:4:4, with hardware acceleration for H.265 encoding, to deliver exceptional video quality at reduced bitrates. Compact form factor, PoE or DC power options, and support for one-to-one or one-to-many configurations make it perfect for any AV environment where you need video content on screens.
1080 60Hz in 4:4:4.
The Darwin HD delivers pristine 1080 resolution at 60Hz with 4:4:4 chroma subsampling, ensuring true-to-life color and exceptional detail.
H.265. Hardware accelerated encoding.
The Darwin HD leverages H.265 hardware acceleration for ultra-efficient video compression, delivering stunning HD quality at reduced bitrates.
DARWIN HD TX
Low latency H.265 HDMI Encoder
DARWIN HD RX
Low latency H.265 HDMI Decoder
DARWIN Control
Advanced Control and Management Box
Add Darwin Control for extra features.
Adding Darwin Control hardware to your Darwin cluster adds a ton of advanced features and simplifies management. Darwin Control enables centralized WebGUI management, API support, and robust security with AES256 encryption, HTTPS, and SSH login. Dual network ports separating AV and control will keep the IT admins happy, while dual RS-232 ports and 4-channel GPIO control enable precise device management and trigger automation. Drag-and-drop routing with video previews and advanced video wall management makes managing your network of Darwin HD Transmitters and Receivers a breeze.
Mineola Dante Audio BridgeS
MINEOLA 2×2
The Mineola 2x2 connects the digital Dante and analog XLR worlds with two inputs and two outputs, perfect for compact setups. PoE-powered and equipped with 48V phantom power on both XLR inputs, it’s ideal for easy microphone connections. All connectors are locking, with Neutrik etherCON on the dual network ports for reliable redundancy. Fully compatible with the entire Dante software suite, the Mineola 2x2 integrates seamlessly into live event production systems including vMix, Vizrt Vectar, Vizrt TriCaster, OBS, Telestream Wirecast. Designed for flexibility and performance, it’s the perfect choice for professional audio applications.
MINEOLA 4×4
The Mineola 4x4 connects the digital Dante and analog XLR worlds with two inputs and two outputs, perfect for compact setups. PoE-powered and equipped with 48V phantom power on both XLR inputs, it’s ideal for easy microphone connections. All connectors are locking, with Neutrik etherCON on the dual network ports for reliable redundancy. Fully compatible with the entire Dante software suite, the Mineola 4x4 integrates seamlessly into live event production systems including vMix, Vizrt Vectar, Vizrt TriCaster, OBS, Telestream Wirecast. Designed for versatility and high performance, it’s the perfect solution for professional audio environments.
MINEOLA 8×8
The Mineola 8x8 seamlessly connects the digital Dante and analog XLR worlds with eight inputs and eight outputs, all housed in a compact 1RU form factor for maximum efficiency. PoE powered and equipped with 48V phantom power on all XLR inputs, it’s perfect for handling high-density audio connections in professional environments. All connectors are locking, featuring Neutrik etherCON on the dual network ports for reliable redundancy. Fully compatible with the entire Dante software suite, the Mineola 8x8 integrates effortlessly into live event production systems like vMix, Vizrt Vectar, Vizrt TriCaster, OBS, and Telestream Wirecast. With its unmatched density and versatility, the Mineola 8x8 is the ultimate solution for demanding audio setups.
Primary and Secondary Dante® networks for redundancy.
Dual network ports allow for Primary and Secondary Dante streams, ensuring redundancy and uninterrupted audio in critical applications.
Total Dante Software Compatibility.
Mineola is 100% compatible with all Dante software products including Dante Controller, Dante Virtual Soundcard (DVS), Dante Domain Manager, Dante Connect, and Dante Director.
PoE with Phantom Power.
Mineola streamlines setups by combining Power over Ethernet (PoE) with 48V Phantom Power on both XLR inputs.
Audio for Live Production.
When combined with Dante Virtual Soundcard (DVS), Mineola connects easily to software-based live production systems including vMix, Vizrt Vectar, Vizrt TriCaster, OBS Studio, and Telestream Wirecast, and all Dante compatible audio systems to provide audio inputs for live event production.
Rack ’Em or Stack ’Em.
The 2x2, 4x4, and 8x8 Mineola can be used as throw down boxes or racked in a 19” rack. This makes Mineola perfect for a variety of uses including on-stage as a mic box, in a lectern for microphone inputs, rackmounted for permanent installations, or rack mounted for use in portable fly away kits for live productions. Whatever your use-case Mineola has you covered and all models include the rack mount kits.
Video Walls and Multiviewers
The Turtle 8x8 Video Wall can be configured as a 1x8 Video Wall, 8x8 Matrix, or 8x1 Multiview. Each input and output supports up to 4K60, 4:4:4 video via HDMI 2.0 with seamless scaling, and audio embedding / de-embedding via optical or line in/out over Phoenix connectors. With WebGUI controls and API integration, it’s the ultimate versatile solution for professional AV environments.
Extremely Powerful Video Wall.
The Turtle 8x8 Video Wall offers a wide range of configurations. Build impressive 4x4 walls, dynamic 2x2 grids, or large 3x3 setups. Create unique layouts like 1x8 panoramas, 2x4 grids, or combine zones for mixed displays. With support for a variety of modes, this system provides the flexibility you need for command centers, public spaces, live events, and more. All in stunning 4K60 resolution.
Dual Independent Multiview.
Two is better than one. Video Wall Display offers dual Multiview outputs each with up to 16 customizable layouts on a single screen for monitoring, presentations, or control rooms. Effortlessly switch between layouts using the WebGUI, API, or front panel controls.
Audio Embedding / De-Embedding.
Seamlessly embed or de-embed audio as needed via the Optical or Phoenix connectors for total flexibility in any AV setup.
8×8 Matrix.
Route any input to any output or create multiple simultaneous configurations with the robust 4x4 Matrix functionality.
4×4 Video Wall
VIDEO WALL, MATRIX, MULTIVIEW. ALL IN ONE.
8×8 Video Wall
VIDEO WALL, MATRIX, MULTIVIEW. ALL IN ONE.
The Dante Adapter Fam.
Dante 2CH Analog XLR Input Adapter with Gain Controls
Two-channel XLR analog audio to Dante 2CH digital audio
Balanced/unbalanced XLR audio input
Dante 2CH Analog XLR Output Adapter with Gain Controls
Dante 2CH digital audio to two-channel XLR analog audio
Balanced/unbalanced analog XLR audio output
Dante audio sampling rate supports 44.1/48/88.2/96KHz@24bit
Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
Analog audio input with support for 5-level gain adjustment
PoE and USB-C power options
TAA compliant
Made from 90% recycled plastic, including 5% Ocean Bound Plastic
Analog XLR to Dante. Plug in. Play Anywhere.
Unlock the power of pristine digital audio with the two-channel XLR analog audio to Dante 2CH digital audio. Built on the cutting-edge Dante Ultimo 2x2 solution, this adapter converts two-channel balanced or unbalanced analog XLR to crystal-clear Dante digital audio.
With 5-level sensitivity adjustment for analog outputs, you can tailor your sound with ease. Additionally, the adapter is powered via USB-C or PoE, ensuring flexible and convenient power options. Perfect for professional-grade audio integrations that demand the best.
Dante 2CH Analog Line Input Adapter with Gain Controls
Two-channel analog audio to Dante 2CH digital audio
Balanced/unbalanced analog audio input
Dante 2CH Analog Line Output Adapter with Gain Controls
Dante 2CH digital audio to two-channel analog audio
Balanced/unbalanced analog audio output
Dante audio sampling rate supports 44.1/48/88.2/96KHz@24bit
Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
Analog audio input with support for 5-level gain adjustment
PoE and USB-C power options
TAA compliant
Made from 90% recycled plastic, including 5% Ocean Bound Plastic
Analog to Dante. Plug in. Play Anywhere.
Unlock the power of pristine digital audio with the Dante 2CH Line Input Adapter. Built on the cutting-edge Dante Ultimo 2x2 solution, this adapter converts crystal-clear Dante digital audio into two-channel balanced or unbalanced analog audio.
With 5-level sensitivity adjustment for analog outputs, you can tailor your sound with ease. Additionally, the adapter is powered via USB-C or PoE, ensuring flexible and convenient power options. Perfect for professional-grade audio integrations that demand the best.
Dante 2CH Bluetooth Input Adapter
Two-channel Bluetooth audio to Dante 2CH digital audio
Supports Bluetooth V5.1, SBC/AAC/APTX/APTX-LL/APTX-HD, up to 24bit/192KHz
Dante audio sampling rate supports 44.1/48/88.2/96KHz@24bit
Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
Analog audio input with support for 5-level gain adjustment
PoE and USB-C power options
TAA compliant
Made from 90% recycled plastic, including 5% Ocean Bound Plastic
Dante 2CH USB-C I/O Adapter
Bi-directional conversion for two-channel USB audio and Dante 2CH digital audio
USB: Class Compliant USB 2.0 device
USB audio output up to 24bit/192KHz
USB audio input up to 24bit/96KHz
Dante audio sampling rate supports 44.1/48/88.2/96KHz@24bit
Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
Analog audio input with support for 5-level gain adjustment
PoE and USB-C power options
TAA compliant
Made from 90% recycled plastic, including 5% Ocean Bound Plastic
Sustainable, Earth-Friendly Design.
Crafted with a commitment to sustainability, our adapter is made from 90% recycled plastic, including 5% Ocean Bound Plastic. The materials have been carefully selected to ensure there is no compromise to the ruggedness or durability. The packaging also contains no plastics or petrochemicals, and the box is made from 100% recycled cardboard and printed with soy-based ink. Turtle AV encourages you to just throw the packaging into the recycling to close the circle.
Dante Ultimo. Accept no substitutes.
In networked audio, precision is essential, and Dante by Audinate delivers with unmatched synchronization and ultra-low latency performance. Leveraging advanced Precision Time Protocol (PTP), Dante ensures every audio packet arrives at exactly the right moment, maintaining audio quality and eliminating jitter, even in complex networks. Turtle AV adapters, powered by the genuine Dante Ultimo chipset, provide seamless compatibility and full interoperability with any Dante-compatible device, ensuring flawless, professional-grade sound for all installations, from live performances to intricate broadcast environments.
Easy Control. 100% Dante Software compatible.
Take command with Dante Controller. Our adapters are fully controllable through this intuitive platform, allowing you to easily manage and adjust settings. With true plug-and-play functionality, your installation is up and running in no time, with no hassle.
Audio stuff.
This adapter converts two-channel balanced or unbalanced analog XLR to crystal-clear Dante digital audio. It offers a versatile Dante audio sampling rate of 44.1, 48, 88.2, and 96KHz at 24-bit, ensuring high-quality sound. The configurable Dante audio delay can be set to 1, 2, or 5 milliseconds, while the analog audio output features 5 levels of sensitivity adjustment, ranging from +24dBu to -10dBv.
The Dante Pro Converter Fam.
2CH Line In
Dante Pro 2CH Analog Line Input Adapter with Gain Controls
Two-channel analog audio to Dante 2CH digital audio
Balanced/unbalanced analog audio input
Dante audio sampling rate supports 24bit 44.1/48/88.2/96KHz
Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
Supports AES67 RTP audio transmission
Analog audio output with support for 3-level gain adjustment: +18dBu, 0dBu (default), and -10dBV
PoE and 12V DC power via phoenix connector
Dante Ultimo Chipset
TAA compliant
Metal case for maximum ruggedness
Analog to Dante. Plug in. Play Anywhere.
Unlock the power of pristine digital audio with the Dante 2CH Line Input Adapter. Built on the cutting-edge Dante Ultimo 2x2 solution, this adapter converts two-channel balanced or unbalanced analog audio into crystal-clear Dante digital audio.
With 3-level sensitivity adjustment for analog outputs, you can tailor your sound with ease. The Dante Pro Dual Line Input is in a rugged metal chassis and can be powered PoE or 12V DC using the phoenix connectors.
Built tough with all metal chassis.
Dante Pro Dual Line Output is housed in an all-metal chassis for maximum ruggedness. And yes, we painted it Turtle Aqua so you know it looks cool even if mounted under a table where no one can see it.
2CH USB I/O
Dante Pro 2CH USB I/O Adapter
Bi-directional conversion for two-channel USB audio and Dante 2CH digital audio
USB: Class Compliant USB 2.0 device
USB audio output up to 24bit/192KHz
USB audio input up to 24bit
Analog sound card, supporting MIC input and SPK output
Dante® audio sampling rate supports 24bit 44.1/48/88.2/96KHz
Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
Supports AES67 RTP audio transmission
PoE and 12V DC power via phoenix connector
Dante Ultimo Chipset
TAA compliant
Metal case for maximum ruggedness
USB to Dante. Plug in. Play Anywhere.
Experience flawless bi-directional conversion between two-channel USB audio and Dante 2CH digital audio. This versatile adapter is USB audio device class 1.0/2.0 compatible, supporting USB output up to 24bit/192KHz and input up to 24bit/96KHz. With Dante® audio sampling rates of 24bit at 44.1, 48, 88.2, and 96KHz, it delivers exceptional audio quality. The configurable Dante audio delay (1, 2, or 5 milliseconds) ensures precision in any setup. Power by PoE or USB-C, for maximum powering flexibility.
Built tough with all metal chassis.
Dante Pro USB I/O is housed in an all-metal chassis for maximum ruggedness. And yes, we painted it Turtle Aqua so you know it looks cool even if mounted under a table where no one can see it.
2CH Line Out
Dante Pro 2CH Analog Line Output Adapter with Gain Controls
Dante 2CH digital audio to two-channel analog audio
Balanced/unbalanced analog audio output
Dante audio sampling rate supports 24bit 44.1/48/88.2/96KHz
Configurable Dante audio delay with support for 1, 2, or 5 milliseconds
Supports AES67 RTP audio transmission
Analog audio output with support for 3-level gain adjustment: +18dBu, 0dBu (default), and -10dBV
PoE and 12V DC power via phoenix connector
Dante Ultimo Chipset
TAA compliant
Metal case for maximum ruggedness
Dante to Analog. Plug in. Play Anywhere.
Unlock the power of pristine digital audio with the Dante 2CH Line Output Adapter. Built on the cutting-edge Dante Ultimo 2x2 solution, this adapter converts crystal-clear Dante digital audio into two-channel balanced or unbalanced analog audio.
With 3-level sensitivity adjustment for analog outputs, you can tailor your sound with ease. The Dante Pro Dual Line Output is in a rugged metal chassis and can be powered PoE or 12V DC using the phoenix connectors.
Built tough with all metal chassis.
Dante Pro Dual Line Output is housed in an all-metal chassis for maximum ruggedness. And yes, we painted it Turtle Aqua so you know it looks cool even if mounted under a table where no one can see it.
Dante Ultimo. Accept no substitutes.
In networked audio, precision is essential, and Dante by Audinate delivers with unmatched synchronization and ultra-low latency performance. Leveraging advanced Precision Time Protocol (PTP), Dante ensures every audio packet arrives at exactly the right moment, maintaining audio quality and eliminating jitter, even in complex networks. Turtle AV adapters, powered by the genuine Dante Ultimo chipset, provide seamless compatibility and full interoperability with any Dante-compatible device, ensuring flawless, professional-grade sound for all installations, from live performances to intricate broadcast environments.
Easy Control. 100% Dante Software compatible.
Take command with Dante Controller. Our adapters are fully controllable through this intuitive platform, allowing you to easily manage and adjust settings. With true plug-and-play functionality, your installation is up and running in no time, with no hassle.
Turtle AV Dante® Adapters are fully compatible with Dante Controller, Dante Domain Manager, and all Dante software applications.
Audio stuff.
This adapter converts Dante 2CH digital audio into two-channel analog audio, supporting both balanced and unbalanced analog outputs. It offers a versatile Dante audio sampling rate of 44.1, 48, 88.2, and 96KHz at 24-bit, ensuring high-quality sound. The configurable Dante audio delay can be set to 1, 2, or 5 milliseconds, while the analog audio output features 3 levels of sensitivity adjustment, +18dBu, 0dBu, and -10dBV.
